Chapter 1: Cyclone III Device Datasheet
Document Revision History
Table 1–40. Document Revision History (Part 2 of 3)
1–33
Date
Version
■
■
■
■
■
Changes
Updated “Operating Conditions” section and included information on automotive device.
Updated Table 1–3, Table 1–6, and Table 1–7, and added automotive information.
Under “Pin Capacitance” section, updated Table 1–9 and Table 1–10.
Added new “Schmitt Trigger Input” section with Table 1–12.
Under “I/O Standard Specifications” section, updated Table 1–13, 1–12 and 1–12.
May 2008
2.0
■
Under “Switching Characteristics” section, updated Table 1–19, 1–15, 1–16, 1–16, 1–17,
1–18, 1–19, 1–20, 1–21, 1–21, 1–23, 1–23, 1–23, 1–24, and 1–25.
■
■
■
■
■
■
Updated Figure 1–5 and 1–29.
Deleted previous Table 1-35 “DDIO Outputs Half-Period Jitter”.
Under “I/O Timing” section, updated Table 1–38, 1–29, 1–32, 1–33, 1–26, and 1–26.
Under “Typical Design Performance” section updated Table 1–46 through 1–145.
Under “Core Performance Specifications”, updated Tables 1-18 and 1-19.
Under “Preliminary, Correlated, and Final Timing”, updated Table 1-37.
December 2007
1.5
■
Under “Typical Design Performance”, updated Tables 1-45, 1-46, 1-51, 1-52, 1-57, 1-58,
Tables 1-63 through 1-68. 1-69, 1-70, 1-75, 1-76, 1-81, 1-82, Tables 1-87 through 1-92,
Tables 1-99, 1-100, 1-107, and 1-108.
■
■
■
■
■
Updated the C VREFTB value in Table 1-9.
Updated Table 1-21.
Under “High-Speed I/O Specification” section, updated Tables 1-25 through 1-30.
Updated Tables 1-31 through 1-38.
Added new Table 1-32.
October 2007
1.4
■
Under “Maximum Input and Output Clock Toggle Rate” section, updated Tables 1-40
through 1-42.
■
■
■
■
■
Under “IOE Programmable Delay” section, updated Tables 1-43 through 1-44.
Under “User I/O Pin Timing Parameters” section, updated Tables 1-45 through 1-92.
Under “Dedicated Clock Pin Timing Parameters” section, updated Tables 1-93 through 1-
108.
Updated Table 1-1 with V ESDHBM and V ESDCDM information.
Updated R CONF_PD information in Tables 1-10.
July 2007
1.3
■
■
■
■
Added Note (3 ) to Table 1-12.
Updated t DLOCK information in Table 1-19.
Updated Table 1-43 and Table 1-44.
Added “Document Revision History” section.
June 2007
1.2
Updated Cyclone III graphic in cover page.
July 2012
Altera Corporation
Cyclone III Device Handbook
Volume 2
